Part number DC Spark-over voltage Vs Insuation resistance IR Electrostatic capacitance 1kHz-6V max. C Surge current Capacity 8/20μs Surge life AC耐電圧 Withstanding Voltage DB60-272M 2,700V(2,160~3,240) 100MΩ min. DC500V 1pF max. 2,000A 8/20μs 100A 200times AC1,000V-1min. AC1,200V-3sec. DB60-302M 3,000V(2,400~3,600) AC1,500V-1min. DB60-362M 3,600V(2,880~4,320) AC1,800V-3sec. DB60-452M 4,500V(3,600～..

Rated voltage Part number DC Spark-over voltage Vs Insuation resistance IR Electrostatic capacitance 1kHz-6V max C Surge current Capacity 8/20μs Surge life AC耐電圧 Withstanding Voltage AC125V DSAZR1-301L 500V（400〜600） ≧100MΩ DC100V ≦2pF 1,000A 8/20μs 100A 300times DSAZR1-501M 600V（480〜720） DC250V DSAZR1-102M 1,100V（880〜1,320） DC500V DSAZR1-242M 2,400V（1,920〜2,880） AC1,000V-1min AC1,200V-3s DSAZR1-..

Part number DC Spark-over voltage Vs Insuation resistance IR Electrostatic capacitance 1kHz-6V max C Surge current Capacity 8/20μs Surge life AC耐電圧 Withstanding Voltage DSA-301LA 300V（255〜345） ≧100MΩ DC100V ≦2pF Lead wire diameter φ0.4mm ：1500A φ0.5mm ：2000A 8/20μs 100A 300times DSA-501MA 500V（400〜600） DC250V DSA-701MA 700V（560〜840） DSA-102MA 1,000V（800〜1,200） DC500V DSA-152MA 1,500V（1,200〜1,800..

Part number DC Spark-over voltage Vs Insuation resistance IR Electrostatic capacitance 1kHz-6V max. C Surge current Capacity 8/20μs Surge life AC耐電圧 AC withstanding voltage DA53-351M 350V（280〜420） ≧100MΩ DC 250V ≦1pF 3,000A 8/20μs 100A 300times DA53-501M 500V（400〜600） DA53-701M 700V（560〜840） DA53-272M 2,700V（2,160〜3,240） DC 500V AC1,000V-1min AC1,200V-3s DA53-302M 3,000V（2,400〜3,600） AC1,500V-1m..

Part number DC Spark-over voltage Vs Insuation resistance IR Electrostatic capacitance 1kHz-6V max. C Surge current Capacity 8/20μs Surge life AC耐電圧 AC withstanding voltage Impulse sparkover voltage 1.2/50μs FA55-272 2,700V （2,160〜3,240) ≧100MΩ DC500V ≦1pF 2,500A 8/20μs 100A 300times AC1,000V-1min AC1,200V-3s 4,500V max. FA55-302 3,000V （2,400〜3,600 AC1,500V-1min 5,000V max. FA55-362 3,600V （2,8..

Part number DC Spark-over voltage Vs Insuation resistance IR Electrostatic capacitance 1kHz-6V max C Surge current Capacity 8/20μs Surge life AC耐電圧 Withstanding Voltage Impulse sparkover voltage 1.2/50μs FA44-272 2,700V （2,160〜3,240) ≧100MΩ DC500V ≦ 1pF 2,000A 8/20μs 100A 300times AC1,000V-1min AC1,200V-3s 4,500V max. FA44-302 3,000V （2,400〜3,600） AC1,500V-1min 5,000V max. FA44-362 3,600V （2,880..

Part number DC Spark-over voltage Vs Insuation resistance IR Electrostatic capacitance 1kHz-6V max. C Surge current Capacity 8/20μs Surge life AC耐電圧 Withstanding Voltage CDA70-701M 700V(560~840) ≧100MΩ DC250V ≦ 0.6pF 2,000A 8/20μs 100A 300times CDA70-102M 1,000V(800~1,200) DC500V CDA70-272M 2,700V(2,160~3,240) AC1,000V-1min. AC1,200V-3sec. CDA70-302M 3,000V(2,400～3,600) AC1,500V-1min CDA70-362M ..
